Incremental Encoder FG 40
10
FG40_MANUAL-en_R12(2018-10-31)ID74490.doc
3.2.2 Output signals Sine / Cosine
Pulse rates
Value
Standard pulse rates
500, 600, 1000, 1024, 1200, 2000, 2048, 2400, 2500
Connection data
Supply voltage
5 V … 30 V DC
No load-current
Approx. 120 mA at 5 V, approx. 50 mA at 24 V
Max. frequency
200 kHz, higher max. frequency on request
Output signals
2 sinusoidal signals A and B each with inverted signals
Reference pulse with inverted signal
Signal amplitude 1 V pp / RL = 120 Ω
Error signal and inverted signal
Signal amplitude 5V
Resolution
1024 signal periodes
Duty cycle
1 ± 0,1
Phase shift A, B
90° ± 1°
