3.3.2 For output signals Sine / Cosine
FG
40
K
1024
S
N
Incremental encoder
Series
connections, radial design
K: Terminal box
R: Burndy
®
-plug
C: Connection cable
L: Fiber optic connection
S: 15-pole EMC industrial plug
KK: 2 terminal boxes, i.e. redundant version
Resolution
1024 signal periods per revolution
Output signals
2 sinusoidal signals A and B each with inverted signals
NG: Option reference pulse with inverted signal
