Incremental Encoder FG 40
18
FG40_MANUAL-en_R12(2018-10-31)ID74490.doc
5.4 Mounting preparations
1. Ensure all accessories are available (please refer to Chapter 11 Dimension drawings).
NOTES!
Fastening screws and earth cable are not included in the range of supply.
2. Preparing the place of attachment: Clean the (motor) shaft, centering, bolting surfaces and
fastening threads; check for damage. Repair any damage!
5.5 Mounting B5 type (flange) incremental encoders
NOTES!
For a mounting example please refer to dimension drawing HM 09 M 57 263a (Chapter 11.1).
)
1
9
2
10
3
12
13
4
7
6
15
8
5
14
17
11
16
Figure 1: FG 40 construction type B5
