Hubner FG 40 Series User Manual

Incremental Encoder FG 40
14
FG40_MANUAL-en_R12(2018-10-31)ID74490.doc
3.3 Type code
3.3.1 For pulse rates (square wave pulses)
FG
40
K
1024
G
90G
NG
2F
S
Incremental encoder
Series
connections, radial design
K: Terminal box
R: Burndy
®
-plug
C: Connection cable
L: Fiber optic connection
S: 15-pole EMC industrial plug
KK: 2 terminal boxes, i.e. redundant
version or with option S
further combined connections available
connections, axial design
AK: Terminal box
AR: Burndy
®
-plug
AC: Connection cable
Pulses per revolution
Basic signal output
Basic channel 0° (A)
Pulse channel 90° (B)
Each with inverted signals
NG: Option reference pulse with inverted signal
N2: Reference pulse, mechanically fixed with
LED check (red)
for display of reference pulse
2F: Option 2F
B: Option B
B2: Option B2
B3: Option B3
S: Option S
Options see pages before
