NOTES!
Prevent lateral pulling forces acting on the cable and plugs so as not to impair the
degree of protection of the cable gland.
6. Connect the supply voltage and signal cable (please refer to the connection diagrams, Chapter
11).
CAUTION!
Do not apply supply voltage to the signal outputs, as this will destroy the device!
7. Applicable to alternative shield connection only: fit cable lug to cable shield and connect to the
shield terminal (please refer to the connection diagrams, Chapter 12).
NOTES!
To achieve a good shielding effect the cable shield be kept as short as possible.
8. Close the terminal box cover.
NOTES!
Before closing the terminal box cover check and if necessary clean both seal surfaces
and the gasket.
CAUTION!
Ensure when closing the terminal box cover that no cable becomes jammed.
9. Secure earth cable to earth terminal (7).
