Fuses Usage
39 Instrument Panel Cluster
40 Run, Accessory
41 Auxiliary Climate Control (Ignition)
42 Rear Defogger
43 SEO B1 Upfitter Usage (Battery)
44 Cigarette Lighter, Auxiliary Power Outlet
45 Special Equipment Option (SEO)
46 Climate Controls (Ignition)
47 Engine Control Module (Ignition)
50 Cooling Fan 1 (J-Case)
51
Electronically Controlled Air Suspension
(J-Case)
52
Vehicle Stability System, Antilock Brake
System-1 (J-Case)
53 Cooling Fan 2 (J-Case)
54 Starter (J-Case)
55 Stud 2 Trailer Brake Module (J-Case)
56 Left Bussed Electrical Center 1 (J-Case)
57
Heated Windshield Washer System
(J-Case)
Fuses Usage
58 Four-Wheel Drive System (J-Case)
59
Stud 1 Trailer Connector Battery Power
(J-Case)
60 Mid Bussed Electrical Center 1 (J-Case)
61 Climate Control Blower (J-Case)
62 Left Bussed Electrical Center 2 (J-Case)
Relays Usage
FAN HI Cooling Fan High Speed
FAN LO Cooling Fan Low Speed
FAN CNTRL Cooling Fan Control
HDLP LO Low-Beam Headlamp
A/C CMPRSR Air Conditioning Compressor
STRTR Starter
PWR/TRN Powertrain
PRK LAMP Parking Lamps
REAR DEFOG Rear Defogger
RUN/CRNK Switched Power
5-116
