Humminbird 858c Combo Operation Manual

117
Specifications (858c DI, 958c DI)
Depth Capability . . . . . . . . . . . . . . . . . . . . . .250 ft (76 m) Down Imaging™,
600 ft (183 m) traditional sonar
Power Output . . . . . . . . . . . . . .500 Watts (RMS), 4000 Watts (Peak to Peak)
Operating Frequency . . . . . . . . . . . . . . . . . . . .XNT 9 DI T: 455 kHz, 800 kHz;
200 kHz and 455 kHz (traditional sonar)
Area of Coverage
XNT 9 DI T
: . . . . . . . . . . .75° @ -10 dB in 455 kHz, 45° @ -10 dB in 800 kHz
XNT 9 DI T (traditional sonar): . . . . . . . . . . . . . . . 25° @ -10 dB in 200 kHz
16° @ -10 dB in 455 kHz
Target Separation . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 1/2 Inches (63.5 mm)
Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-20 VDC
LCD Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .480 V x 800 H
Transducer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .XNT 9 DI T
Transducer Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 ft (6 m)
Current Draw
858c DI
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .950 mA
958c DI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .825 mA
IPX Rating . . . . . . . . . . .IP67 Waterproof/Submersible @ 1 m for 30 minutes
and dust tight
NOTE: Product specifications and features are subject to change without notice.
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions,
however actual depth performance may vary due to transducer installation,
water type, thermal layers, bottom composition and slope.
Specifications (898c SI, 998c SI)
Depth Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1500 ft (500 m)
Power Output . . . . . . . . . . . . . .500 Watts (RMS), 4000 Watts (Peak to Peak)
Operating Frequency
Side Imaging®: . . . . . . . . . . . . . . . . . .200 kHz and 83 kHz, 455 kHz, 800 kHz
Area of Coverage
DualBeam PLUS™
: . . .60° @ -10 dB in 83 kHz and 20° @ -10 dB in 200 kHz
Side Imaging®: . . . . . . . . . .455 kHz: (2) 86° @ -10 db (180° Total Coverage)
800 kHz: (2) 55° @ -10 db (130° Total Coverage)
Target Separation . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 1/2 Inches (63.5 mm)
Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-20 VDC
LCD Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .480 V x 800 H
Transducer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .XHS 9 HDSI 180 T
Transducer Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 ft (6 m)
Current Draw
898c SI
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .950 mA
998c SI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .850 mA
IPX Rating . . . . . . . . . . .IP67 Waterproof/Submersible @ 1 m for 30 minutes
and dust tight
NOTE: Product specifications and features are subject to change without notice.
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions,
however actual depth performance may vary due to transducer installation,
water type, thermal layers, bottom composition and slope.
