31 MEGA Live Imaging Views
MEGA Live/2D Sonar Combo View
The MEGA Live/2D Sonar Combo View shows sonar information and MEGA Live Imaging information in a combination split screen,
where the 2D Sonar View is displayed on the left and the MEGA Live View is displayed on the right.
Active Side
APEX/SOLIX: The selected pane is outlined in yellow. Tap a pane or press the PANE key
to select a pane.
HELIX: The arrow points to the active side. Press the MENU key once and select Active
Side from the X-Press Menu. Choose RIGHT or LEFT to set the active side.
X-Press Menu
After you set the Active Side, press the MENU key once to open the X-Press Menu. The
X-Press Menu provides menu options for the active view.
NOTE: On APEX and SOLIX, you can also access the X-Press Menu by tapping the menu in the
status bar.
Sonar Use the 2D traditional Sonar View with the MEGA Live View to maximize your sonar data.
MEGA Live/Sonar View (APEX) MEGA Live/Sonar View (HELIX)
active side indicator
active side
