38MEGA Live Mode
Set the Display Mode
When using your transducer in Down or Forward Mode, you can set the width of the data displayed in Down Mode or select the angle
used for Forward mode.
APEX/SOLIX Series HELIX Series
1. With a MEGA Live View or MEGA Live Combo View displayed
on-screen, press the MENU key once, or tap Sonar (MEGA
Live) on the status bar.
2. Select Down Display Mode or Forward Display Mode. Tap,
or use the Joystick and ENTER key, to select a setting.
1. With a MEGA Live View or MEGA Live Combo View displayed
on the screen, press the MENU key once.
2. Select Down Display Mode or Forward Display Mode.
Press the RIGHT or LEFT Cursor key to adjust the setting.
Down Display Mode
Narrow: Select Narrow to see only the data directly under the transducer.
Full: Select Full to reveal more information than Narrow.
Wide: Select Wide to display the maximum information available from the MEGA Live
beam width.
Forward Display Mode
Select the angle of your transducer (see Understanding the MEGA Live Modes for more
information), or select Auto for your control head to select the best angle for you.
