5
A Control Dial
Run Normal dial position for automatic
operation
Set Date/Time Set current date and time
Set Program Start
Times
Set 1 to 4 start times in each program
Set Station Run
Times
Set run time for each station
Set Days to Water Select individual days to water, odd,
even, or interval watering schedule
Set P/MV
Operation
Enable or disable the Pump or Master
Valve for each station
Seasonal
Adjustment
Apply global adjustments to station run
times based on seasonality (5% to 300%)
Solar Sync
Sensor
Allows user to program settings when
using Solar Sync ET Sensor
Manual — Single
Station
Activates one-time watering of a
single station
B Wiring Compartment
9 V Battery An alkaline battery (not included) allows
programming of the controller facepack
without AC power
Reset Button Resets the controller, keeping all
programmed data intact
SmartPort Input
Terminals
Used to connect a SmartPort Wiring
Harness, which enables Hunter remote
controls
Transformer Internal 24 VAC transformer, prewired
with power cord and plug
Junction Box Wiring compartment that provides an area
for connecting primary AC power to the
controller
Common Terminal Used for eld Common connections to
solenoid valves; also used to complete
sensor circuit wiring
Sensor
Inputs (x 2)
Used to connect Hunter Solar Sync and
Clik Sensors
Power Slide Slide power lock On and O when inserting
and removing PCM output modules
Built on Innovation
®
Pro-C Controller Components
