23 TECHNICAL DATA 104

23.8 Shock absorber

Shock absorber part number 12.45.7M.69

Shock absorber WP Suspension PDS 5018 DCC

Compression damping, low-speed

Comfort 25 clicks

Standard 20 clicks

Sport 15 clicks

Compression damping, high-speed

Comfort 2 turns

Standard 1.5 turns

Sport 1.25 turns

Rebound damping

Comfort 28 clicks

Standard 24 clicks

Sport 22 clicks

Spring preload 9 mm (0.35 in)

Spring rate

Weight of rider: 65… 75 kg (143… 165 lb.) 69 N/mm (394 lb/in)

Weight of rider: 75… 85 kg (165… 187 lb.) 72 N/mm (411 lb/in)

Weight of rider: 85… 95 kg (187… 209 lb.) 76 N/mm (434 lb/in)

Spring length 250 mm (9.84 in)

Gas pressure 10 bar (145 psi)

Static sag 33… 35 mm (1.3… 1.38 in)

Riding sag 105… 115 mm (4.13… 4.53 in)

Fitted length 417 mm (16.42 in)

Damper oil Shock absorber oil (SAE 2.5) (50180342S1) ( p. 107)

23.9 Chassis tightening torques

Screw, pressure regulator EJOT PT

3 Nm (2.2 lbf ft) –

Spoke nipple, front wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –

Spoke nipple, rear wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –

Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –

Screw, intake air temperature sensor M5 2 Nm (1.5 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Nut, cable on starter motor M6 4 Nm (3 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, throttle grip M6 5 Nm (3.7 lbf ft) –

Fuel connection on fuel pump M8 10 Nm (7.4 lbf ft) –

Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Nut, rim lock M8 12 Nm (8.9 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –
