14 WHEELS, TIRES 74
101848-11
Main work
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
–
Change the wheel bearing. x
– Clean and grease the shaft seal rings 1 and bearing surface A of the spacers.
Long-life grease ( p. 108)
– Insert the spacers.
101849-10
– Lift the rear wheel into the swingarm, position it, and insert wheel spindle 2.
– Attach the chain.
101849-10
– Position chain adjusters 3. Mount nut 4, but do not tighten it yet.
– Make sure that chain adjusters 3 are fitted correctly on adjusting screws 5.
– Check the chain tension. ( p. 57)
– Tighten nut 4.
Guideline
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Info
The wide adjustment range of the chain adjusters (32 mm (1.26 in))
enables different secondary ratios with the same chain length.
Chain adjusters 3 can be turned by 180°.
– Operate the foot brake lever repeatedly until the brake linings are in contact with
the brake disc and there is a pressure point.
Finishing work
– Remove the motorcycle from the lift stand. ( p. 41)
14.5 Checking the tire condition
Info
Only mount tires approved and/or recommended by HUSABERG.
Other tires could have a negative effect on handling characteristics.
The type, condition, and air pressure of the tires all have a significant impact on the handling characteristics of the motorcycle.
The tires mounted on the front and rear wheels must have a similar profile.
Worn tires have a negative effect on handling characteristics, especially on wet surfaces.
400602-10
– Check the front and rear tires for cuts, run-in objects, and other damage.
» If the tire exhibits cuts, run-in objects, or other damage:
– Change the tire.
– Check the depth of the tread.
Info
Note local national regulations concerning the minimum tread depth.
Minimum tread depth ≥ 2 mm (≥ 0.08 in)
