11 TUNING THE CHASSIS 81
– Install the air filter box.
– Mount the side cover. ( p. 91)
– Mount the seat. ( p. 90)
– Remove the motorcycle from the work stand.
11.12 Adjusting the riding sag
Preparatory work
– Raise the motorcycle with the work stand.
– Remove the seat. ( p. 90)
– Take off the side cover. ( p. 91)
– Remove the air filter box.
– Remove the shock absorber.
– After removing the shock absorber, clean it thoroughly.
201352-10
Main work
– Choose and mount a suitable spring.
Guideline
Spring rate
Medium (standard) 75 N/mm (428 lb/in)
Hard 80 N/mm (457 lb/in)
Info
The spring rate is shown on the outside of the spring.
Finishing work
– Install the shock absorber.
– Install the air filter box.
– Mount the side cover. ( p. 91)
