Husqvarna AUTOMOWER 310 User Manual

3012-1381
3012-1301
3012-1307
English - 8
INTRODUCTION AND SAFETY
Moving
The original packaging should be used when transporting
the robotic lawnmower over long distances.
To safely move from or within the working area:
1. Press the STOP button to stop the robotic
lawnmower. If security is set to the medium or
high level (see 6.4 Security on page 46) the PIN
code has to be entered. The PIN code has four
digits and is chosen when the robotic lawnmower
is started for the rst time, see 3.8 First start-up
and calibration on page 33.
2. Set the main switch to position 0.
3. Carry the robotic lawnmower by the handle
found at the rear of the product. Carry the robotic
lawnmower with the blade disc away from the
body.
IMPORTANT INFORMATION
Do not lift the robotic lawnmower when
it is parked in the charging station. It
can damage the charging station and/or
the robotic lawnmower. Press STOP and
instead rst pull the robotic lawnmower
out of the charging station before lifting it.
OM_1157863-26_HQ 310,315,EN_160229.indd 8 2016-02-29 10:51:30

Husqvarna AUTOMOWER 310 Specifications

General

Cutting Width	22 cm
Cutting Height Min	20 mm
Cutting Height Max	50 mm
Battery Type	Li-ion
Typical Charging Time	60 min
Typical Mowing Time per Charge	70 min
Maximum Incline Within the Working Area	40%
Working Area Capacity	1000 m²
Battery Capacity	2.1 Ah
Weight	9.4 kg
Battery Voltage	18 V
Operating Time	70 min
Maximum Area	1000 m²
Weather Resistance	Yes
Smart Connectivity	No
Blade Type	Pivoting razor blades
