15 ELECTRICAL SYSTEM
108
– Install the air filter box cover. ( p. 68)
15.4 Changing main fuse
Warning
Fire hazard Incorrect fuses overload the electrical system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
Info
The main fuse protects all electrical power consumers of the vehicle.
Preparatory work
– Remove the air filter box cover. ( p. 68)
– Remove the seat. ( p. 67)
S04846-12
Main work
–
Pull EFI control unit
1
upward off the rubber lugs
2
and
hang to the side.
S04849-10
–
Pull starter relay
3
from the holder.

Husqvarna TE 300 Specifications

General

Displacement	293.2 cc
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP XPLOR-USD, Ø 48 mm
Front Brake	Disc brake
Rear Brake	Disc brake
Seat Height	950 mm
Engine Type	1-cylinder, 2-stroke
Rear Suspension	WP XACT shock absorber with linkage
Dry Weight	105 kg
Fuel Tank Capacity	8.5 liters
