12 SERVICE WORK ON THE CHASSIS
68
F02310-10
–
Mount and tighten screw
1
.
Guideline
Screw, seat fixing M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the air filter box cover. ( p. 68)
12.20 Removing the air filter box cover
F02311-10
–
Pull off the air filter box cover sideways in areas
A
,
B
and
C
and take off toward the rear.
12.21 Installing the air filter box cover
F02312-10
–
Attach catch
1
of the air filter box in area
A
and push for-
ward.
F02311-11
–
Engage the air filter box cover in areas
B
,
C
and
D
.

Husqvarna TE 300 Specifications

General

Displacement	293.2 cc
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP XPLOR-USD, Ø 48 mm
Front Brake	Disc brake
Rear Brake	Disc brake
Seat Height	950 mm
Engine Type	1-cylinder, 2-stroke
Rear Suspension	WP XACT shock absorber with linkage
Dry Weight	105 kg
Fuel Tank Capacity	8.5 liters
