15 ELECTRICAL SYSTEM

114

15.6 Removing the headlight mask with the headlight

H03749-10

–

Loosen rubber straps

. Push the headlight mask upwards

and pivot it to the right.

H03748-10

–

Remove screw

– Detach the brake line and wiring harness from the headlight

mask.

– Pivot the headlight mask forwards and place it on the fender.

H03750-10

(All EU models)

–

Detach plug-in connectors

and take off the headlight

mask with the headlight.

H03751-10

(All US models)

–

Disconnect plug-in connector

and take off the head-

light mask together with the headlight.

15.7 Installing the headlight mask with the headlight

H03750-11

Main work

(All EU models)

–

Join plug-in connectors
