12 SERVICE WORK ON THE CHASSIS
64
H03690-10
Main work
–
Remove screws
1
.
–
Remove screws
2
. Take off the front fender.
12.15 Installing front fender
H03690-10
Main work
–
Position front fender. Mount and tighten screws
1
and
2
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the headlight mask with the headlight. ( p. 114)
– Check the headlight setting. ( p. 117)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Husqvarna TE 300i US 2021 and is the answer not in the manual?

Husqvarna TE 300i US 2021 Specifications

General IconGeneral
Displacement293.2 cc
Bore72 mm
Stroke72 mm
Transmission6-speed
Seat Height950 mm
Front Brake260 mm disc
Starting SystemElectric Start
Ground Clearance370 mm
Engine Type2-stroke single cylinder
Front SuspensionWP Xplor 48 mm fork
Rear Brake220 mm disc
FrameChromium molybdenum steel
Wheelbase1485 mm
Fuel SystemElectronic Fuel Injection
