6 CONTROLS
22
6.18 Opening 2-stroke oil tank cap
V01647-10
–
Fold loop
1
upward.
– Turn the 2-stroke oil tank cap counterclockwise and pull it
up.
6.19 Closing 2-stroke oil tank cap
V01648-10
– Put the 2-stroke oil tank cap on and turn it clockwise.
–
Fold loop
1
down.
The 2-stroke oil tank cap engages.
6.20 Cold start button
H03660-10
The cold start button
1
is fitted on the side of the throttle valve
body.
If the engine is cold and the ambient temperature is low, the
electronic fuel injection system extends the injection time. To
help the engine burn the increased fuel quantity, it must be sup-
plied with additional oxygen by pulling the cold start button.
Info
If the engine is warm, the cold start button must be deac-
tivated.
Possible states
• The cold start button is activated – The cold start button is
pulled out all the way and turned by a ¼ turn.
• The cold start button is deactivated – A further ¼ turn
returns the cold start button back to the basic position.

Husqvarna TE 300i US 2021 Specifications

General

Displacement	293.2 cc
Bore	72 mm
Stroke	72 mm
Transmission	6-speed
Seat Height	950 mm
Front Brake	260 mm disc
Starting System	Electric Start
Ground Clearance	370 mm
Engine Type	2-stroke single cylinder
Front Suspension	WP Xplor 48 mm fork
Rear Brake	220 mm disc
Frame	Chromium molybdenum steel
Wheelbase	1485 mm
Fuel System	Electronic Fuel Injection
