Husqvarna VIKING Designer EPIC User Manual

Program – Overview
You can combine stitches and/or letters and numbers to
create stitch programs. Combine various decorative stitches
and stitch fonts from the mySewnet™ cloud folder on the
machine or from a USB device.
You can combine program stitches up to approximately 500
mm (20”) long. You can see how long your stitch program is
at the top of the window. You can program in both sewing
and in embroidery edit.
Tip: If sewing mode is active and your stitch program is ready to be sewn,
you can close the program window by pressing the foot control, or by
pressing the start/stop button.
Note: Not all stitches are available to program. A pop-up message will
alert you if you try to select an unavailable stitch.
1. Program length
2. Step to previous stitch/go to last
3. Step to next stitch/go to first
4. STOP command
5. FIX command
6. Thread cut command
7. Duplicate
8. Delete
9. Mirror end to end
10. Mirror side to side
11. Cursor
12. Stitch length/Stitch density
13. Stitch width/Stitch positioning
14. Save
15. JoyOS advisor™ project viewer
16. Open keyboard
17. Cancel program
18. OK, return to sewing mode
19. File manager
20. Font menu
21. Stitch menu
22. JoyOS advisor™ project menu
23. Minimize/expand selection area
154 10 Program

Husqvarna VIKING Designer EPIC Specifications

General

Category	Sewing Machine
Brand	Husqvarna VIKING
Model	Designer EPIC
Stitch Width	9 mm
Built-in Stitches	Over 1200
USB Ports	Yes
WiFi Capability	Yes
Needle Positions	37
Needle Threader	Automatic
Stitch Positioning	Yes
Automatic Presser Foot Lift	Yes
Automatic Thread Cutter	Yes
Type	Computerized
Embroidery Designs	Over 650
Maximum Sewing Speed	1050 stitches per minute
Built-in Memory	Yes
Sewing Space Height	140 mm
Sewing Space Width	310 mm
Bobbin Winding	Automatic
Screen	Large Interactive Touch Screen
