Husqvarna VIKING Designer EPIC User Manual

Embroidery Unit
(type EU 22)
1. Embroidery unit release button (underside)
2. Embroidery arm
3. Embroidery hoop attachment
4. Level adjustment feet
5. Embroidery unit plug
When removing the embroidery unit from the box for the
first time, be sure to remove the shipping brace on the
underside of the embroidery unit.
Embroidery Hoop Overview
1. Embroidery hoop connector
2. Outer hoop
3. Inner hoop
4. Quick release
5. Retaining screw
6. Ribs for fitting the clips
7. Center marks
Sensor Q-Foot
The Sensor Q-foot is recommended for hoop embroidery.
See Attaching the Sensor Q-Foot, page 44.
48 3 Embroidery Preparations

Husqvarna VIKING Designer EPIC Specifications

General

Category	Sewing Machine
Brand	Husqvarna VIKING
Model	Designer EPIC
Stitch Width	9 mm
Built-in Stitches	Over 1200
USB Ports	Yes
WiFi Capability	Yes
Needle Positions	37
Needle Threader	Automatic
Stitch Positioning	Yes
Automatic Presser Foot Lift	Yes
Automatic Thread Cutter	Yes
Type	Computerized
Embroidery Designs	Over 650
Maximum Sewing Speed	1050 stitches per minute
Built-in Memory	Yes
Sewing Space Height	140 mm
Sewing Space Width	310 mm
Bobbin Winding	Automatic
Screen	Large Interactive Touch Screen
