• Upper thread is cut automatically at the start of a jump
stitch.
• Cut commands in designs, stitches or programs.
Designs marked with this symbol are
programmed for automatic jump stitch trim.
Jump stitch trim commands can be added to
any design using the complimentary software
(PC).
Tip: Hold the thread tail when you start embroidering or at a new color
block so that you can easily remove the thread end when cut.
Tip: If the front and back of your embroidery will be visible, turn off the
automatic jump stitch trim and cut the threads manually.
Tip: If your designs are very close together, e.g. lettering or programmed
stitches, turn off the automatic jump stitch trim and cut the thread
manually.
Twin Needle Options
When a twin needle size is selected the deLuxe™ Stitch
System will automatically use thread tension. When
embroidering with a twin needle the Straight Stitch Plate
needs to be removed as it cannot be used together with a
twin needle. The twin needle setting will automatically be set
when loading a twin needle embroidery project from the
JoyOS advisor™ project menu.
Note: It is very important to activate the twin needle setting when
embroidering with a twin needle to prevent damage to the machine.
168 11 Settings

Husqvarna VIKING Designer EPIC Specifications

General

Category	Sewing Machine
Brand	Husqvarna VIKING
Model	Designer EPIC
Stitch Width	9 mm
Built-in Stitches	Over 1200
USB Ports	Yes
WiFi Capability	Yes
Needle Positions	37
Needle Threader	Automatic
Stitch Positioning	Yes
Automatic Presser Foot Lift	Yes
Automatic Thread Cutter	Yes
Type	Computerized
Embroidery Designs	Over 650
Maximum Sewing Speed	1050 stitches per minute
Built-in Memory	Yes
Sewing Space Height	140 mm
Sewing Space Width	310 mm
Bobbin Winding	Automatic
Screen	Large Interactive Touch Screen
