FNGSC-A Self Contained Merchandisers
LOAD LIMITS
Each merchandiser has a load limit decal. Shelf
life of perishables will be short if load limit is
violated.
AT NO TIME SHOULD MERCHANDISERS BE
STOCKED BEYOND THE LOAD LIMITS INDICATED.
DO NOT BLOCK AIR LOUVERS.
Air flow in food compartment:
The main task of the air flow subsystem in
the food compartment is to distribute cold
air across the display case. Cold discharge
air blowing through the honeycomb creates
an air curtain that acts as an invisible barrier
between the cold air inside and the warm air
outside the case. This barrier helps to minimize
infiltrations and keeps cold air inside the case.
Make sure product is loaded below limit so
that the air curtain continues is not disrupted.
STOCKING
Product should NOT be placed inside the
merchandisers until merchandisers are at
proper operating temperature.
Allow merchandiser 24 hours to operate before
loading product.
Proper rotation of product during stocking is
necessary to prevent product loss. Always
bring the oldest product to the top and set the
newest to the bottom.
AIR DISCHARGE AND RETURN FLUES MUST
REMAIN OPEN AND FREE OF OBSTRUCTION AT
ALL TIMES to provide proper refrigeration
and air curtain performance. Do not allow
product, packages, signs, etc. to block these
grilles. Do not use non-approved shelving,
baskets, display racks, or any accessory that
could hamper air curtain performance.
Do not allow product to be placed outside of
the designated load limits in the illustration.
INSTALLING FDA/NSF REQUIRED
THERMOMETER
These models have a thermometer. The
thermometer is located at the top, interior of
the merchandiser.
Honeycomb
LOAD LIMIT
AIR
INTAKE
AIR
EXHAUST
(FNGSC8A shown)
(FNGSC8A shown)
