P/N 3141959_C 5-5
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
FNGSC-A Self Contained Merchandisers
REPLACING DRAIN HEATER
Unplug the power cords before servicing.
1. Remove product and place in a refrigerated
area. Make sure the power is off to the
case.
2. Make sure there is no voltage in the
refrigerator. Remove pan displays to have
access to the evaporation section.
7. Take off compressor screws.
8. Remove welded joints to the compressor
and replace with new compressor.
9. Reverse the process and make sure
everything is in place.
FNGSC8A Condensing Unit Shown
FNGSC8A Condensing Unit Shown
Parts may be ordered at Hussmann’s Performance
Parts e-store:
https://parts.hussmann.com/
or
Call toll free: 855-487-7778
Required Tools:
• Screwdriver / Philips Tip
• 1/4" Allen Wrench
FNGSC8A Condensing Unit Access
