5-6 SERVICE
P/N 3141959_C U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
REPLACING PAN HEATER
Unplug the power cords before servicing.
1. Remove product and place in a refrigerated
area. Make sure the power is off to the case.
2. Make sure there is no voltage in the
refrigerator. Remove lower panels.
3. Slide out the condensing unit completely
(Fig B). Be careful using the condensing
unit base to pull it out. Make sure not to
stress or interfere with other parts.
3. Remove front lower panel and take off the
electric enclosure box cover.
4. Disconnect the evap heater harness from
Wago connectors.
5. Remove clip jiffies and replace the drain
heater. Ensure the harness routed as it was
previously.
Parts may be ordered at Hussmann’s Performance
Parts e-store:
https://parts.hussmann.com/
Call toll free: 855-487-7778
or
Required Tools:
• Screwdriver / Philips Tip
• 1/4" Allen Wrench
FNGSC8A Shown
FNGSC8A Shown
FNGSC8A Shown
