1-2 INSTALLATION
P/N 3141959_C U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
LOCATION
Product should always be maintained at
proper temperature. This means that from the
time the product is received, through storage,
preparation and display, the temperature of the
product must be controlled to maximize the
life of the product.
BE SURE TO POSITION SELF CONTAINED
MERCHANDISERS PROPERLY.
These models have vented base panels to allow
air circulation through the condensing unit.
Allow for a minimum 30" clearance from walls,
merchandisers, and any other large objects near
the merchandiser’s vented base panels (for self
contained models). Blocking or restricting air
flow will adversely affect performance and may
damage the refrigeration system.
MODEL DESCRIPTION
FNGSC models are island, spot display
merchandisers. Each self contained model will
have two self-contained units with one dual
circuited evaporator.
FNGSC models are designed for dual
temperature operation. These models
have upper glass on all four sides of the
merchandiser.
UNLOADING
Unloading from Trailer:
Lever Bar (also known as a Mule, Johnson
Bar, J-bar, Lever Dolly, or Pry Lever)
Move the merchandiser as close as possible to
its permanent location and remove all packaging.
Check for damage. Remove all separately
packed accessories. Improper handling may
cause damage to the merchandiser when
unloading.
To avoid damage:
1. Do not drag the merchandiser out of the
trailer. Use a Johnson bar (mule). Use a
forklift or dolly to remove the merchandiser
from the trailer.
2. Use caution when moving case to
setup location. Use care to not damage
refrigeration system. Confirm there are
no refrigerant leaks during startup of the
case(s).
AIR
INTAKE
AIR
EXHAUST
4 IN
CLEARANCE
30" Clearance
