Hussmann Q3 - Electrical Wiring Diagrams

22
HUSSMANN_GDF_1.1 SHEET SIZE D
MATERIAL - N/A
THIRD
ANGLE
PROJECTION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES.
DRAWN BY -CRAIG BOOREY
APPROVED BY - CRAIG BOOREY
TOLERANCES ARE:
DECIMALS .XX
u
.03, .XXX
u
.010
ANGLES
u
2
v
DATE DRAWN - 2-1-18
ECN-CAP-0011187
REVIEWED BY -CRAIG BOOREY
REF -
3055096
DIAGRAM-Q3-MV-BC-8R W/AK-CC-210 FOR /MISTING SYSTEM
REV ECN DATE REVISION DESCRIPTION REV BY CHKD BY APPR BY
A ECN-CAP-0011187 2018/02/01 RELEASED TO PRODUCTION CB CB CB B ECN-CAP-0011188 2018/02/02 REMOVED AIR SWEEP HEATER CB CB CB C ECN-CAP-0011190 2018/02/09 ADDED FIELD INSTRUCTIONS CB CB CB D ECN-CAP-0011191 2018/02/14 ADDED ADDITIONAL FIELD INSTRUCTIONS CB CB CB
REVISION HISTORY
NOTES: CASE MUST BE GROUNDED WHEN PASSING WIRES THROUGH METAL HOLES A GROMMET MUST BE USED
D
SHEET 1 OF 3
CIRCUIT #1
L1
LOADING
4.4
120V
SHELVES
LIGHT CIRCUIT 0.91A 98.6W @ 120V
MCA= 1.14A MOP= 15A
~120 VAC - 60 Hz.
LED DRIVER
BUNDLE ORANGE
BLK #14
WHT#14
L1 N
RED +
BLUE -
BUNDLE BROWN
~120 VAC - 60 Hz.
M M
M
M
MCA= 1.1A MOP= 15A
L1 N
BLACK #14
WHITE #14
AIR SWEEP FAN (2) 0404551 15W .20A @120VAC
EVAP FAN MOTOR (4) 0477653 4W .12A @120VAC
M
M
4' L.E.D. LIGHT HO
LIGHT SWITCH TIPPETTE 125-01-0311
LED DRIVER
RED +
BLUE -
4' L.E.D. LIGHT
RJ-45 NETWORK JACK 125-01-0202
INCOMING POWER ~120 VAC -60 Hz
GFCI DUPLEX 125-01-3178
BLK # 14
WHT # 14
GRN # 14
ALL SINGLE RECEPTACLES TO BE TIED TO DUPLEX GFCI RECEPTACLE
BUNDLE YELLOW
CIRCUIT #2
4' L.E.D. LIGHT
4' L.E.D. LIGHT
4' L.E.D. LIGHT
4' L.E.D. LIGHT
4' L.E.D. LIGHT
CIRCUIT #3
4' L.E.D. LIGHT HO
CANOPY
3' L.E.D. LIGHT
3' L.E.D. LIGHT
4' L.E.D. LIGHT
4' L.E.D. LIGHT
LEDGE
L
Electrical Wiring Diagram
