Hussmann Q3 - Joining Case to Case

15
Q3 MV-BC JOININGCASETOCASE-STEP 1
Gaskets (factory installed)
Butyl
Apply
gasket to case area as shown.
1
/
2
"(13 mm) gasket areappliedinthe recess along
the top canopy frameand vertical arm.
Apply
butyland silicone to case area as shown
.
Apply silicone a
pplicationasshown to properly
seal area.Ensure thatbeads of silicone are minimum of
1
/
2
"to
maximize adhesivejoining preventing airleakage.Besuretowipe
o anyaxcesssiliconearoundcases.
IMPORTANT
. Do notstretch gasket,especialy around thecorners
.Donot butt gasket,alwaysoverlap .Removepaper backing aftergaskethas been applied
C
Applybeadofsilicone
to theexteriorfaceofgasket
Gaskets (factory installed)
DETAIL C
Installation (cont’d)
