DISCHARGE AIR GRILLS: The discharge grills are positional. The center grills all have the same outlet
pattern. The case ends (defined as bordering a case end panel) will have a slightly more open pattern.
Ensure that the grills are located in the correct positions:
PN 3052 446. Left hand grill
as viewed from the front of
the case. 1 per case or line-
up.
PN 3052447. Right hand grill
as viewed from the front of
the case. 1 per case or line-
up.
PN 3052448. Center grill. In
all positions except ends.
See above.
