5. Malfunction at Frame Reader
5.1 Stylus goes up and is stuck. Sometimes repeats up-down and then, stops.
5.2 Frame shapes are significantly different or distorted.
5.2.1 Perform maintenance referring to 5.1
5.2.2 Perform Frame & Pattern Calibration.
5.3 Strange noise from the inside of the Frame Reader.
Stylus doesn’t move to the left or right and starts reading at wrong position.
Yes
No
Is the 14-Pin cable damaged?
Yes
Replace the 14-pin cable.
Refer to Maintenance book.
No
Is the 20-Pin flat cable
damaged?
Yes
Replace the 20-pin flat cable.
Is there anything on the
stylus cover?
Yes
Remove it and try again.
No
Is the Frame Reader fell down
or shocked?
Yes
Adjust X-moving Ass
’
y referring
to Maintenance book.
Is the room temperature
under 10
º
C or the Frame
Reader had been in cold
atmosphere for a long time?
Warm the room temperature at least more
than 10
º
C and try again.
To Next Page
