SECTION 3
PARAMETER INDEX
MINIFLEX LR
Application
Pr. 1.0 Basic Application
Basic Set-up
Pr. 2.0 Empty Distance
Pr. 3.0 Operational Span
Pr. 4.0 Blanking
Pr. 5.0 Rate Of Change
Volume Measurement
Pr. 6.1 Vessel shape
Pr. 6.2 Display Units
Pr. 6.3 Maximum Display x 100
Pr. 6.4 Display Format
Open Channel Flow Monitoring (O.C.M.)
Pr. 7.1 Flow device
Pr. 7.2 Maximum Flow Value Type
Pr. 7.3 Maximum Flow
Pr. 7.4 Totaliser Units
Pr. 7.5 External Totaliser Drive
Pr. 7.6 Totaliser Reset
Relays
Pr. 8.1 Relay1 Options
Pr. 8.2 Relay2 Options
Pr. 8.3 Relay3 Options
Pump Control
Pr. 9.1 Pump Sequence
Pr. 9.2 Duty Standby
Pr. 9.3 Exerciser
Pr. 9.4 Tolerance
Pr. 9.5 Maintenance
Pr. 9.6 Pump Run-on Interval
Pr. 9.7 Pump Run-on Time
Failsafe
Pr. 10.1 Relay 1 Failsafe
Pr. 10.2 Relay 2 Failsafe
Pr. 10.3 Relay 3 Failsafe
Pr. 10.4 Fail Time
Pr. 10.5 mA Fail
Analogue
Pr. 11.1 Analogue Output
Pr. 11.2 Analogue Value
Pr. 11.3 Test mA
Pr. 11.4 Analogue Scale
Miscellaneous
Pr. 12.1 Offset
Pr. 12.2 Passcode
Pr. 12.3 Number Of Decimals
Pr. 12.4 Relay totaliser
Pr. 12.5 Simulation
Pr. 12.6 Station ID
Pr. 12.7 Synchronisation
Pr. 12.8 Check Search
Pr. 12.9 Maximum gain
Ref: MINIFLEX LR MANUAL Rev. 0 14
