SECTION 3
PROGRAMMING THE INSTRUMENT
NOTE:- (D = ) factory default entry for that parameter.
Step 1: - Select application (Pr.1.0)
Application (D = Distance Measurement)
This will automatically load the applicable default program which can then be
modified to suit your application.
At initial start up display will show one of below listed options: -
Distance Measurement (Page 35)
Level Measurement (Page 36)
Volume Measurement (Page 37)
Pump Control (Page 38)
Open Channel Flow Monitoring (Pages 39 – 40)
Differential Measurement (Pages 41 – 42)
For more details see Pr.1.0 Application Selection Guide (Page 16)
Step 2: - Enter Basic Set-up parameters
Complete Basic Set-up section - Page 17
Step 3: - Dependent on application, go to appropriate section in manual.
For Distance Measurement go to Page 35.
For Level Measurement go to Page 36.
For Volume Measurement go to Page 37.
For Pump Control go to Page 38.
For Open Channel Flow Monitoring go to Pages 39 - 40.
For Differential Measurement go to Pages 41 - 42.
Step 4: - Set any relay conditions
Relay section go to Pages 24 - 26
Step 5: - Set any failsafe conditions
Failsafe section go to Page 30
Step 6: - Set any analogue conditions
Analogue section go to Pages 31 - 32
Step 7: - Set any miscellaneous conditions
Miscellaneous section go to Pages 33 - 34
Step 8: - Exit program mode and return to run mode
Go to Section 7 Page 13
Ref: MINIFLEX LR MANUAL Rev. 0 15
