APPENDIX 2
SPECIFICATION
Transceiver
Enclosure : IP65, NEMA 4X, IK08 / IK07 polycarbonate, hinged lid.
Dimensions : 185H X 213W X 119.5D (mm).
Weight : 1.55Kg
Power Supply : 95/110/230VAC +
10%. 50/60Hz, 12VA,
24V DC + 25% - 10%, 9W. Separate terminals.
Fuse Rating : F3 T160mA for AC supply
F4 T250mA for 24V DC supply
F1 & F2 T80mA.
Range : Up to 10 metres.
Accuracy of Change in
Level
: +
0.25% of measured distance from the transducer at constant
temperature of 20ºC,
Ambient Temperature : -20ºC to + 70ºC.
Resolution : 2mm or 0.1% of range, whichever is the greater.
Analogue Output : 4-20mA into 750 Ohms. 16 bit. Short circuit protected and opto-
isolated on AC powered units. Not opto-isolated on 24V DC units.
Relay Outputs : 3 multi-function SPDT relays rated 8A/250VAC/30V DC resistive,
with gold contacts.
Indication : Integral display, 2lines x 16digit Backlit LCD.
3 red LED's to indicate relay status.
Interface : 5 key integral keypad with security code.
Failsafe : High, Low, Hold
Damping : Fully adjustable
Blanking : Fully adjustable
Transducer
Type : RYV15 RYT15 RWV15 RWT15
Temperature
Compensation
: No Yes No Yes
Frequency (in KHz) : 41.5 kHz 41.5 kHz 41.5 kHz 41.5 kHz
Beam Angle at 3dB : 12 degrees @
-3dB
12 degrees @
-3dB
12 degrees @
-3dB
12 degrees @
-3dB
Body Material : Solvay Solef
6008 (PVDF)
Solvay Solef
6008 (PVDF)
Solvay Solef
6008 (PVDF)
Solvay Solef
6008 (PVDF)
Face Material : Glass reinforced
epoxy
Glass reinforced
epoxy
Solef 6008
(PVDF)
Solef 6008
(PVDF)
Process Temperature * : -40ºC to + 90ºC -40ºC to + 90ºC -40ºC to + 90ºC -40ºC to + 90ºC
Protection : IP68
IP68 IP68 IP68
Weight (Kg) : 1.5 1.5 1.5 1.5
Hazardous area approval* EEx m II T6 KEMA 04ATEX1124X
Temperature range –40 to +60ºC
NOTE: CE approved - EMC tested in accordance with BS EN61000-6-2: 2001 &
BSEN61000-6-3 including A1 & C1
Low voltage directive, EN61010
* Refer to pages 54 & 55 for ATEX installations.
Ref: MINIFLEX LR MANUAL Rev. 0 53
