APPENDIX 4
DISTANCE APPLICATION PARAMETERS
Pr Description Factory Default User Service
Application
1.0 Basic Application Distance
Basic Set-up
2.0 Empty Distance 10.00
3.0 Operational Span 10.00
4.0 Blanking 0.500
5.0 RateOfChange 10.00
Relays
8.1 Rly1 Options Off
8.1.1.1 R1 Set NOT APPLICABLE
8.1.1.2 R1 Reset NOT APPLICABLE
8.2 Rly2 Options Off
8.2.1.1 R2 Set NOT APPLICABLE
8.2.1.2 R2 Reset NOT APPLICABLE
8.3 Rly3 Options L.O.E. Alarm
8.3.1.1 R3 Set NOT APPLICABLE
8.3.1.2 R3 Reset NOT APPLICABLE
Failsafe
10.1 Relay 1 NOT APPLICABLE
10.2 Relay 2 NOT APPLICABLE
10.3 Relay 3 De-Energise
10.4 Fail Time 600
10.5 mA Fail Hold
Analogue
11.1 Analogue O/P Output 4-20mA
11.2 Analogue Value NOT APPLICABLE
11.3 Test mA 4mA
11.4 Analogue Scale NO VALUE REQUIRED
11.4.1 Datum (%) 0.0
11.4.2 Span (%) 100.0
Miscellaneous
12.1 Offset 0.000
12.2 Passcode 36.67
12.3 NoOfDecimal 2 Dec Points
12.4 Relay tot. Off
12.5 Simulation No
12.6 Station ID 1
12.7 Sync Instrs Master
12.8 Check Search Off
12.9 Maximum gain 100.0
NOT APPLICABLE – Parameter is not required for the selected option but may need to be set if the option is
changed.
NO VALUE REQUIRED – This parameter is just a heading and leads to another parameter.
Ref: MINIFLEX LR MANUAL Rev. 0 56
