APPENDIX 4
VOLUME APPLICATION PARAMETERS
Pr Description Factory Default User Service
Application
1.0 Basic Application Level
Basic Set-up
2.0 Empty Distance 6.000
3.0 Operational Span 5.500
4.0 Blanking 0.500
5.0 RateOfChange 1.000
Volume Conversion
6.1 Vessel Shape Linear
h Metres NOT APPLICABLE
R Metres NOT APPLICABLE
Dish L Metres NOT APPLICABLE
Cylindr L Metres NOT APPLICABLE
6.2 Display Units %
6.3 MaxDisp *100 001.0
6.4 Disp. Format Contents
Relays
8.1 Rly1 Options Norm-Energised
8.1.1.1 R1 Set 90.00%
8.1.1.2 R1 Reset 85.00%
8.2 Rly2 Options Norm-Energised
8.2.1.1 R2 Set 10.00%
8.2.1.2 R2 Reset 15.00%
8.3 Rly3 Options L.O.E. Alarm
8.3.1.1 R3 Set NOT APPLICABLE
8.3.1.2 R3 Reset NOT APPLICABLE
Failsafe
10.1 Relay 1 Hold State
10.2 Relay 2 Hold State
10.3 Relay 3 Hold State
10.4 Fail Time 600
10.5 mA Fail Hold
Analogue
11.1 Analogue O/P Output 4-20mA
11.2 Analogue Value NOT APPLICABLE
11.3 Test mA 4mA
11.4 Analogue Scale NO VALUE REQUIRED
11.4.1 Datum (%) 0.0
11.4.2 Span (%) 100.0
Miscellaneous
12.1 Offset 0.000
12.2 Passcode 36.67
12.3 NoOfDecimal 2 Dec Points
12.4 Relay tot. Off
12.5 Simulation No
12.6 Station ID 1
12.7 Sync Instrs Master
12.8 Check Search Off
12.9 Maximum gain 100.0
NOT APPLICABLE – Parameter is not required for the selected option but may need to be set if the option is
changed.
NO VALUE REQUIRED – This parameter is just a heading and leads to another parameter.
Ref: MINIFLEX LR MANUAL Rev. 0 58
