Pg. 2.7
FUNCTION BFUNCTION B
FUNCTION BFUNCTION B
FUNCTION B
UTTUTT
UTTUTT
UTT
ON DESCRIPTIONON DESCRIPTION
ON DESCRIPTIONON DESCRIPTION
ON DESCRIPTION
If a red indicator light above a function button is illuminated, it means that the function printed in red at the top of the
button is enabled. No light indicates the the function printed in black at the bottom of the function button is enabled. The
following are the function buttons for AUTO and MAN modes:
AUTO MODE - This button is held for 5 seconds to recall or set the "KERF" value.
MAN MODE - 1) This button is used to reset the "LTH" counter to zero.
2) If pressed and held in for a few seconds, the HEAD HOME cycle will be initiated.
NOTE: Before using SINGLE CUT or AUTO, it is necessary to "HOME THE HEAD". This must be
repeated any time the hydraulic system has been shut down so the machine knows where it's
HOME position is.
AUTO / MAN MODE - This button will toggle between MAN and AUTO modes. Auto mode cannot be accessed
unless front vise is closed.
- Also used to stop an automatic job in progress by switching to MANUAL mode.
AUTO MODE - This button will allow editing of a job to be executed.
MAN MODE - This button will advance the shuttle vise toward the head (home position) and if pressed
simultaneously with "REV", to recall parameters. (Front vise must be in the closed position to
gain access to parameters)
AUTO MODE - This button will allow viewing of the current QUEUE or the editing of a new QUEUE to be
executed.
MAN MODE - This button will retract the shuttle vise away from the head and if pressed simultaneously
with "FWD", to recall parameters. ( Front vise must be in the closed position to gain access to
parameters)
AUTO MODE - This button is disabled.
MAN MODE - This button will toggle between FAST and SLOW speed for the shuttle vise.
AUTO / MAN MODE - This button toggles to allow length values to be displayed either in millimeters or inches
and the blade speed in either surface feet per minute or meters per minute. It becomes
disabled once an AUTO cycle is initiated.
FAST
SLOW
METRIC
INCH
AUTO
MAN
QUEUE
REV
JOB
FWD
KERF
CLEAR/HOME
