Pg. 2.11
To fill the QUEUE, follow these two steps.
1) Key in a job number and press ENTER. If that job number has previously been programmed, it's values will be
displayed. The cursor will move to the next position in the QUEUE. Up to five jobs may be in the QUEUE at any
time. The job values cannot be edited in this mode.
2) When the desired jobs have been entered, you may press the CYCLE START button on the control panel to
execute the jobs in the QUEUE. (Follow the same procedures to initiate a cycle as in "AUTOMATIC
OPERATION")
At completion of the "QUEUE", the machine will shut down.
KERF CORRECTIONKERF CORRECTION
KERF CORRECTIONKERF CORRECTION
KERF CORRECTION
When making mitred cuts, the part length must be set longer than the desired length by an amount we will call the
"KERF CORRECTION" This is due to the fact that the PLC does not account for a difference in the kerf value at various
angles. The standard kerf and corrected values are as follows:
STD KERF @ 90DEG 75 60 55 50 45 40 35 30
1" BLADE .059 .061 .068 .072 .077 .083 .092 .103 .118
1 1/4" BLADE .066 .068 .076 .081 .086 .093 .103 .115 .132
1 1/2" BLADE .074 .077 .085 .090 .097 .105 .115 .139 .148
2" BLADE .086 .089 .094 .105 .112 .122 .134 .150 .172
