Hydac CS1000 series User Manual

Reading the analog output
Fluid temperature TEMP
The current range 4.8-19.2 mA or voltage range 2.4-9.6 V is, depending on
the fluid temperature of -25°C-100°C (resolution: 1°C) or -13°F-212°F
(resolution: 1°F), as shown in the table below.
Current I
Temperature / Error
Voltage U
I < 4.00 mA
Cable break
U < 2.00 V
4.0 mA < I < 4.1 mA
Device error /
The CS is not ready
2.00 V < U < 2.05 V
4.1 mA < I < 4.3 mA
Not defined
2.05 V < U < 2.15 V
4.3 mA < I < 4.5 mA
Flow error
(The flow rate is too low.)
2.15 V < U < 2.25 V
4.5 mA < I < 4.8 mA
Not defined
2.25 V < U < 2.40 V
I = 4.8 mA
-25 °C / -13 °F
U = 2.40 V
…
…
…
I = 19.20 mA
+100 °C / 212 °F
U = 9.60 V
19.2 mA < I < 19.8 mA
Not defined
9.60 V < U < 9.90 V
19.8 mA < I < 20 mA
No measured value
9.90 V < U < 10 V
The current I or voltage U can be calculated for a given temperature as
follows:
I = 4.8 mA + (temperature [°C] + 25) x (19.2 mA - 4.8 mA) / 125
I = 4.8 mA + (temperature [°F] +13) x (19.2 mA - 4.8 mA) / 225
U = 2.4 V + (temperature [°C] + 25) x (9.6 V - 2.4 V) / 125
U = 2.4 V + (temperature [°F] + 13) x (9.6 V-2.4 V) / 225
The temperature in °C or °F can be calculated for a given current I or
voltage U as follows:
Temperature [°C]= ((I - 4.8 mA) x (125 / 14.4 mA)) - 25
Temperature [°F]= ((I - 4.8 mA) x (225 / 14.4 mA)) - 13
Temperature [°F]= ((U - 2.4 V) x (125 / 7.2 V)) - 25
Temperature [°F]= ((U - 2.4 V) x (225 / 7.2 V)) - 13
ContaminationSensor CS1000
en(us)
Page 102 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
