Hydraulic sensor connection
Determine the operating pressure of the hydraulic system and see whether it
is within the permissible flow range for the CS inlet.
NOTICE
Excessive operating pressure
The ContaminationSensor will be destroyed.
► Note the maximum operating pressure of 350 bar / 5075 psi.
If possible, install the CS so that fluid flows from bottom to top to avoid air
collecting in the sensor. If it is not possible to install it like that, take other
measures to ensure that air cannot collect in the sensor.
Use port A / C as the INLET and B / D as the OUTLET.
ContaminationSensor CS1000
en(us)
Page 22 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
