Hydac CS1000 series User Manual

Hydraulic sensor connection
Connecting hydraulic sensor
NOTICE
Excessive operating pressure
The ContaminationSensor will be destroyed.
► Note the maximum operating pressure of 350 bar / 5075 psi.
Observe the following sequence when connecting the sensor to the hydraulic
system:
1.
Connect the return line to the OUTLET of the CS. G1/4 ISO 228
threaded connection, recommended diameter of line ≥ 4 mm.
2.
Then connect the other end of the return line to the system tank, for
example.
3.
Check the pressure at the measurement location. Note the maximum
operating pressure.
4.
Connect the measurement line to the INLET port of the CS.
Connector threads G1/4 ISO 228. We recommend an internal Ø ≤
4mm for the line in order to prevent particle deposits (sedimentation).
If particles ≥ 400 µm are anticipated in the hydraulic systems,
install a protective screen upstream from the ContaminationSensor.
(e.g. CM-S). This prevents any clogging of the measuring cell.
5.
Connect the other end of the measurement line to the measurement
point on the hydraulic system.
Oil begins to flow as soon as the ContaminationSensor is
connected with the pressure line.
6.
The hydraulic connection is complete.
ContaminationSensor CS1000
en(us)
Page 27 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
