Hydac CS1000 series User Manual

Technical Data
Hydraulic data
Permitted operating pressure
maximum 350 bar / 5075 psi
Hydraulic connection
- Pipe or hose connection
Thread G ¼ according to ISO 228
- Flange connection
DN 4
Permitted measurement flow
rate
30 … 500 ml/min
Permissible viscosity range
1 to 1000 mm²/s
Fluid temperature range
0 …80 °C / 32 …185 °F
Electrical data
Connection plug
M12x1, 8 pole, specified in DIN VDE 0627
Power supply
9 … 36 V DC, residual ripple < 10%,
(protected against polarity reversal)
Power consumption
3 W max.
Analog output
2-conductor technology
4 … 20 mA active output
(max. burden 330Ω)
or
2 … 10 V active output
(minimum load resistance 820 Ω)
Switching output
passive, n-switching Power MOSFET:
maximum switching current 2 A,
maximum switching voltage 30 V DC,
dead open
RS485 interface
2 wire, half duplex
HSI (HYDAC Sensor Interface)
1 wire, half duplex
ContaminationSensor CS1000
en(us)
Page 119 / 136
BeWa CS1000 3764916d 300 en-us 2017-09-25.docx 2017-09-25
