H Y D R O P O O L I N D U S T R I E S
23
TO CHECK/CHANGE THE SET TEMPERATURE
The last measured temperature is constantly
displayed on the topside control. When either of these pads
is pressed once, the display will show the set temperature.
Press either pad a second time to increase or decrease the
set temperature. After 3 seconds the display will once again
show the last measured temperature.
The temperature can be adjusted from 80˚F to 104˚F in
1˚ increments
PUMPS / JETS FUNCTION
from left to right on topside control – P1, P2, *P3
(*Titanium series only)
PUMP 1 (P1)
1
st
press – turns on low speed – the P1 icon
spins slowly
2
nd
press – turns on high speed – the P1 icon
spins faster
3
rd
press – turns off pump – no icon displayed
when P1 is off
When P1 low is already operating, the 1
st
press of the P1
pad puts the pump directly into high speed.
Low speed P1 starts automatically every 30 minutes to
measure water temperature (in STANDARD Mode only – see
MODE FUNCTION), when a filter cycle is activated, or when
a freeze condition is detected.
When P2, P3 or the blower is manually activated, P1 low
speed is automatically activated and operates until the
pump(s) or blower time out. If P2, P3 or the blower is turned
on even briefly, and then turned back off, P1 low will
operate for a minimum of 2 minutes.
PUMP 2 (P2)
1
st
press – turns on high speed – the P2 icon
spins fast
2
nd
press – turns off pump – no icon displayed
when P2 is off.
PUMP 3 (P3) – TITANIUM SERIES ONLY
1
st
press – turns on high speed – the P3 icon
spins fast
2
nd
press – turns off pump – no icon displayed
when P3 is off.
PUMPS AUTOMATIC TIME-OUT
P1 high speed, P2 & P3 – 15 minutes
P1 low speed – 4 hours.
CLEAN-UP CYCLES
The Clean-up Cycle begins 30 minutes after the pump(s)
or blower have been turned off or have automatically
timed-out. P1 low speed and the ozonator (optional) will
operate for one hour.
SETTING THE SYSTEM CLOCK TIME
The flashes on the topside control display upon initial
start-up. This reminder will disappear once the clock time
is programmed.
Press then to enter programming mode.
To set the hour: Press or - each press changes the
time by 1 hour.
Press to enter, and to continue to set minutes.
To set minutes: Press or - each press changes the
time by 1 minute.
Press the pad again to continue to the filter cycle
programming mode (see below)
OR
Press the pad to exit programming mode.
During normal operation, pressing the pad will display
the current time for 3 seconds.
FILTER CYCLES
Once the system clock time has been programmed, the
system will automatically activate P1 low speed to filter the
water for 2 hours twice each day. During the filter cycle, the
display will show FILTER 1 or FILTER 2.
FACTORY PRESET DEFAULT
‘FILTER 1’ the system automatically activates P1 low to
operate from 8 AM to 10 AMThe filter 1 LED indicator will
light during filter cycle 1 operation.
‘FILTER 2’ the system automatically activates P1 low to
operate from 8 PM to 10 PM The filter 2 LED indicator will
light during filter cycle 2 operation.
