H Y D R O P O O L I N D U S T R I E S
26
INITIAL START-UP
When you initially power up your Hydropool hot tub, it will
default to the factory preset temperature, 100˚F (38˚C), and
filtration cycle F3 (see FILTER CYCLES). Anytime power to
your hot tub is interrupted, the system will default to these
settings.
TEMPERATURE ADJUSTMENT
The current water temperature is continually
displayed on the topside control panel.
TO CHECK THE SET TEMPERATURE:
Press this pad and the display will flash the set temperature
for a few seconds. When it stops flashing, the display will
again show the current water temperature.
TO CHANGE THE SET TEMPERATURE
Press this pad and the display will flash the set temperature.
While the display is still flashing, press the temperature pad
a second time. Each subsequent press will change the set
temperature in the same direction. To adjust the tempera-
ture in the opposite direction, wait a few seconds for the
display to stop flashing (until it displays the current water
temperature), then press the pad again.
The temperature is adjustable as follows:
4˚C; 16˚C to 26˚C in 2˚ increments; 26˚C to 40˚C in 1˚increments.
PUMPS/JETS FUNCTION
Press this pad to activate the pump(s)
SINGLE PUMP SYSTEM (P1)
1st press – turns on low speed of pump
2nd press – turns on high speed of pump
3rd press – turns off high speed of pump
DUAL PUMP SYSTEM (P1 & P2)
1st press – turns on low speed of P1
2nd press – turns on high speed of P1
3rd press – turns on P2
4th press – turns off high speed of P1
5th press – turns off P2
The low speed pump will start automatically when the
system calls for heat, when a filter cycle is activated, or
when a freeze condition is detected. When low speed is
already on, the 1st press of the pad puts the pump
directly into high speed.
PUMPS AUTOMATIC TIME-OUT
P1 high speed and P2 – turn off after 15 minutes
P1 low speed – turns off after 4 hours
CLEAN-UP CYCLE
After P1 high speed is turned off either manually or
automatically, P1 low speed circulates for 1 hour.
FILTER CYCLES
Your hot tub control system automatically activates P1 low
speed to filter the water twice each day (one filter cycle
every 12 hours). The first filter cycle begins 1 minute after
your hot tub is initially powered up. The second filter cycle
will begin 12 hours after the start of the first filter cycle.
The duration of the filter cycle (length of time P1 low runs)
is programmable from the topside control panel, and can be
set for F3, F4, F6, F8, FC (filter continuously).
Example: F3 represents 3 hours of filtration every 12 hours
(3 hrs on, 9hrs off)
PROGRAMMING FILTER CYCLES
To change the factory defalt filter cycle settings, press the
following pads within 3 seconds of each other:
Press Then Then press
Press to lock in your selection and exit the
programming sequence.
PURGE CYCLE
If your hot tub is equipped with a second pump (P2) and/or
a blower, the system will automatically activate each for 30
seconds at the beginning of every filter cycle.
HYDR O P O O LHYDR O P O O L
OPTIONAL
SPA CONTROL SYSTEM – EUROPE
GOLD, PLATINUM, SERENITY/MILLENIUM SERIES
SYSTEM CONTROL HPL103/105, TOPSIDE PANEL SUP. DUP.
