3.0 Additional Functions
14 CC1092267A
Go to the [CONTROL MENU] sub-menu and then the
p
2
TIMER CONTROL menu item. You will now see the
p
2
TIMER CONTROL OFF default setting. If you press
the key, the OFF value starts to flash. Use the
key to change the value to ON. Then press the key
again to confirm the entry. The timer is now switched on
for the second pressure range. Refer to Section 3.1.2
for how to set the parameters for the 2nd pressure
range.
3.4 [LIMIT VALUES] sub-menu
Sub-menu [LIMIT VALUES] are the factory-set and
changeable parameters, SS or RS represent single or
regulated speed:
a) DESIGN PRESS 8.0 bar (116 psi)
b) START PROTECT 2.0 bar (29 psi)
c) HEAVY STARTUP (SS) 3.5 bar
d) EXT. LIMIT (RS) 2000RPM
e) FINAL TEMP WARN 107°C (225°F)
f) FINAL TEMP MAX 110°C (230°F)
g) MIN START TEMP 0°C (32°F)
h) RUN-ON TIME 60s
i) SOFT STOP 2s
j) STAR DELTA TIME (SS) 1s
k) SOFTWARE (SS) HPro-V1.xx
l) SOFTWARE(RS) HPro-RS-V1.xx
Note
Values shown are examples only, those used in your
unit may be different.
a) This is your unit's operating pressure. This is also
stamped on the compressor's rating plate.
b) As protection, the compressor only starts up when
the internal pressure is less than or equal to the set
value. If the internal pressure is higher when starting
up, the following appears in the display's third row.
WARNING START AFTER ...
alternating with
... DE-PRESSURISE
c) If the internal pressure builds up too quickly when
the compressor starts up, there is an error in the
unit. To protect the motor in the case of an error, the
compressor shuts down if pressure builds up too
quickly. FAULT HEAVY STARTUP appears in the
third row on the display.
d) If an input is programmed on the function [EXT.
RPM LIMIT] and its contact is closed, the speed of
the compressor will be restricted to the value set
here.
e) If the compressor temperature reaches 107°C
(225°F), WARNING HIGH TEMP appears in the
display's third row.
f) If the compressor temperature reaches 110°C
(230°F), the compressor shuts down. FAULT COMP
TEMP then appears in the third row on the display
g) If the compressor temperature is below 0°C (32°F ),
the compressor cannot start up.
h) If the compressor is in automatic mode and there is no
pressure requirement, the RUN-ON TIME xxxs
indication appears and the compressor goes into off-
load. After the run-on time (xxx), the compressor
automatically shuts down and is ready to start again. If
using the timer or the remote start / stop function, the
run-on time is also used.
i) In order to protect the compressor, once the key
has been pressed, the compressor is switched off 2
seconds later. If using the timer or the remote start /
stop function, the run-on time is also used.
j) During the start-up phase, a change is made from star
to delta (contactors in starter panel) following the set
value.
k) Shows the software version of your single speed (SS)
electronic controller CC1054325.
l) Shows the software version of your regulated speed
(RS) electronic controller CC1068566.
3.5 [OPTIONAL IN-/OUTPUTS] sub-menu
3.5.1 Inputs
Attention
Only potential-free contacts may be connected to the
terminal strip. External voltages will destroy the
HYDROVANE Pro.
The potential-free contacts must not be more than 20
metres away from the terminal strip. If necessary
coupling relays must be fitted in the control cabinet.
The HYDROVANE Pro has programmable inputs, some
are already assigned (programmed) when supplied. Inputs
and their functions are shown in the circuit diagram of the
compressor.
Inputs are programmed in the [OPTIONAL IN-/OUTPUTS]
sub-menu. In the sub-menu press the key to display the
INPUT 1: menu item.
If you press the key, the function starts to flash. By
pressing the or key, you can change the function.
Once you have set the function you want, confirm using the
key. The input is now programmed.
You access all other programmable inputs by pressing the
or key.
Each input can be programmed with any of the functions
listed below.
Explanation of functions:
FREE
Input is not assigned (programmed).
EXT FAULT
If the contact is opened, the EXT FAULT fault message
appears on the display and the unit is shut down (shutting
down is delayed by 1sec.).
EXT WARNING
If the contact is opened, the EXT WARNING warning
message appears on the display (the indication is delayed
by 1sec.). This function does not result in the unit shutting
down.
