3.0 Additional Functions
___________________________________________________________________________________________________
CC1092267A 15
DRYER FAULT
If the contact is opened, the DRYER FAULT fault
message appears on the display and the unit is shut
down (shutting down is delayed by 1sec.).
DRYER WARNING
If the contact is opened, the DRYER WARNING
warning message appears on the display (the indication
is delayed by 1 sec.). This function does not result in
the unit shutting down.
ENAB.REM.LOAD
For use and examples, see Section 3.8.3.
REMOTE LOAD
For use and examples, see Section 3.8.3.
EXT. RPM LIMIT
When the contact is closed the speed of the
compressor is restricted to the set speed in the menu
[LIMIT VALUES] in menu item EXT. LIMIT.
RTC OVERRIDE
The timer can be overridden using this input.
Example: The compressor has been shut down by the
timer. If the contact is now closed, the compressor
starts up.
2
nd
PR. RANGE
If the contact is closed, the system changes over to the
second pressure range. Also refer to section 3.1.2.
ENAB.REM-START
For use, see section 3.8.5.
OPERATE_B1
For use, see section 3.8.4.
3.5.2 Outputs
Attention
The maximum connected loads for the programmable
outputs (relay contacts) are 4,5A / 240V.
The HYDROVANE Pro has programmable outputs,
some are already assigned (programmed) when
supplied. Outputs and their functions are shown in the
circuit diagram of the compressor.
Outputs are programmed in the [OPTIONAL IN-
/OUTPUTS] sub-menu. In the sub-menu press the
key to display OUTPUT 1: menu item
If you press the key, the function starts to flash. By
pressing the or key, you can now change the
function. Once you have set the function you want,
confirm using the key. The output is now
programmed.
You access the other programmable output by pressing
the key.
Each output can be programmed with any of the
functions listed below.
Explanation of functions:
OFF
Output is not programmed.
OPERATING
The output (relay) is activated when the compressor's
motor is switched on or when the compressor is ready.
ON-LOAD
The output (relay) is activated when the compressor is in
on-load.
OFF-LOAD
The output (relay) is activated when the compressor is in
off-load.
FAULT
The output (relay) is activated when there are no faults on
the compressor.
WARNING
The output (relay) is activated when there are no warnings
on the compressor.
MAINT.DUE
The output (relay) is activated when there are no
maintenance messages on the compressor.
WARNING/MAINT.
The output (relay) is activated when there are no warnings
and no maintenance messages on the compressor.
WARN/MA/FAULT
The output (relay) is activated when there are no warnings,
no maintenance messages and no faults on the
compressor.
REM.STARTABLE
The output (relay) is activated when the compressor is
ready for the remote start.
RUNNING
The output (relay) is activated when the compressor's
motor is running (is switched on).
2nd PR. RANGE
The output (relay) is activated when the 2nd pressure
range is applicable.
TIMER
The output (relay) is activated when the compressor is
switched on by the internal timer.
