3.0 Additional Functions
16 CC1092267A
3.6 Locking / unlocking code
Settings (sub-menus) can be locked using a code to
prevent unauthorised programming.
Limit values cannot be changed by the operator.
Locking
Press the key for 5 seconds, the following message
appears on the display:
CODE: UNLOCK (for 1 second) followed by CODE
INPUT 0000 (0000 value flashes)
Enter code: 3031, the following message appears:
CODE: LOCK (for 1 second)
The sub-menus are locked and cannot be changed.
If the wrong code is entered, the following message
appears:
CODE: UNLOCK (for 1 second)
The display then automatically jumps back to where it
started from.
Unlocking
If the code is to be unlocked again, either:
Press the key for 5 seconds when not in the menu
or when attempting to change a protected value in a
sub-menu.
The code prompt then appears:
CODE LOCK (for 1 second) followed by CODE INPUT
0000 (0000 value flashes)
Enter code: 3031.
If the code is entered correctly, the following message
appears:
CODE: UNLOCK (for 1 second)
If the code is entered incorrectly, the following message
appears:
CODE: LOCK (for 1 second)
The display then automatically jumps back to where it
started from.
3.7 Replacing the HYDROVANE Pro
Once a new HYDROVANE Pro has been fitted, switch
the isolator back on.
One of the following now appears on the display with
either the 6.0 BAR or KEB 400V flashing:
*** Hydrovane ***
SETUP PRESSURE: 6.0 BAR
*** Hydrovane ***
VSD-TYPE: KEB 400V
Use the key to select either the working pressure or a
KEB 460V/Mitsubishi VSD, press the key to confirm
your entry.
The following now appears on the display with the 07 figure
flashing (11 if Mitsubishi is selected):
***..Hydrovane..***
HV MODEL: 07RS
Use the key to select the required model, press the
key to confirm your entry, the following message appears
on the display.
INITIALIZATION VSD...
After a short delay the displayed message will change to
READY TO START
If the wrong selection is made, WRONG VSD MODEL
appears, hold the key to reach 2222 and press the
key to start again.
If the correct entry is made, the compressor automatically
switches to its delivery status.
The language has been reset to English. If you need a
different language, set as described in Section 1.4.
You now have to set the maximum and minimum supply
pressure as shown in Section 1.5.
You then have to repeat the individual programming for the
inputs and outputs. Consult your compressor's circuit
diagram, it shows how inputs and outputs are configured.
The [OPTIONAL IN-/OUTPUTS] Section 3.5 shows how to
program inputs and outputs.
