Hydrover OXYMATIC smart - Technical Specifications; Controller Technical Specifications

Installation, Programming and Maintenance User Guide Oxymatic Smart
V. 1.3.2. May 2015


40

14. CONTROLLERTECHNICALSPECIFICATIONS.
Av. de la Industria Nº 6-8 Nave 17
28108 Alcobendas – Madrid – España
Tel. +34 902 500 132 Fax: +34 916 591 272
www.hydrover.eu
OXYMATIC - SMART 02 de Enero 2015
STANDAR EQUIPMENT
PLUS EQUIPMENT (Available March
2015)
* WORKING PARAMETERS
Mains supply 100 to 250 Vca 50/60 Hz
Yes
Max temp working Range +5 to +55 ºC (Avoid direct sunligth)
Yes
Max Humidity Working Maximum 95% (Non condensed)
Yes
Increase internal temperature due to working use Increased in 12ºC
Yes
* READOUT PARAMETERS
pH readout Range 5 to 10 pH units, two decimals
Yes
Rx readout Range +/-
2.000 mV
Yes
Cu++ readou
t
No
Yes (3 concentrations decades)
Residual Chlorine readout No
Yes
Conductivity readou
t
No
Yes
Biocide readou
t
No
Yes
Water Temperature Range +5 to +55 ºC (temperature sensor included)
Yes
* SCREEN PARAMETERS
Screen type High Resolution Graphics
Yes
Screen Color Full Color
Yes
Screen Size 10"
Yes
Parameters Programation Touch screen patterns
Yes
Type of programation Friendly Intuitive
Yes
Numbers of parameters in the screen Full parameters shown at time
Yes
* INPUTS & OUTPUT's
Oxydation Current Out Adjustable from 6 to 12 amps
Yes
Ionization Current Out Adjustable from 1 to 4 amps (Under order 0 to 12 amps)
Yes
Peroxide Peristaltic Ou
t
Yes (230 Vca peristaltic)
Yes
pH Peristaltic Pump Control Yes (230 Vca peristaltic)
Yes
Rx Peristaltic Pump Con
t
rol Yes (230 Vca peristaltic)
Yes
Cu++ Peristaltic Pump Control No
Yes (230 Vca peristaltic)
Residual Chlorine control No
ON/OFF free contacts Out
Conductivity control No
ON/OFF free contacts Out
Recirculating Pump out ON/OFF Yes
Yes
Recirculating Pump out proportional (Varioflow) No
0/10 vcc PWM
ECO Discaling Output No
Yes by means PWM & magnets
ECO Discaling Chamber No
PWM
Swimming Pool Level Control No
Up 3 levels detections
Domotics Control (Presence detector) No
Yes
Domotics Control (TV Camera) No
Yes
Cover Out Free Contacts Continuous or Pulse Out
Yes
Ligths Out Free Contacts Time Adjustable
Yes
Heat Pump Out Adjustable Temp & Timming.
Yes
Heat Pump Control ModBus No
RS485 with ModBus Protocol
* ALARMS
Level Control in pH Reactive Container Minimum Level
Yes
Level Control in Rx Reactive Container Minimum Level
Yes
Level Control in Cu++ Reactive Container Minimum Level
Yes
Water temperature High & Low
Yes
pH values High & Low
Yes
Rx values High & Low
Yes
Cu++ values No
High & Low
Oxydation Current Out High & Low
Yes
Ionization Current Out High & Low
Yes
Residual Chlorine No
High & Low
Conductivity No
High & Low
Recirculating Pump Damaged
Yes
Swimming Pool Level Control No
Minimum Level
Domotics Control (Presence detector) No
Yes
Heat Pump Out Adjustable Temp & Timming
Yes
* WIRELESS COMUNICATIONS
WiFi Yes
Yes
3G communications No
Yes
SmartPhone capabilities Yes
Yes
iCloud Hydrover Server No
Yes
iCloud Local Server (for local maintenance purposes) No
Yes
* WORKING PROGRAMS
Manual Mode Every
Yes
Fully Automatic
Basic Automatic Program & Six Pre-programed modes
(Winter & Summer) & USER Yes
Off Mode Yes
Yes
* NORMATIVE & SECURITY According to Low Voltage Normative ITC-BT 031 (2002)
According to Elec
t
rical Security & Electromagnetic
7323/ECC/EN61010-1 (93)
* SICE 275x345x110
* WEIGHT 4,5 Kg
