EN-GB - 15HYENA E-BIKE SYSTEMS
Unplug the downtube cable. Pull the range extender lock tab in an
upwards direction to unlock it.
Turn the range extender from the bottom
insertion to loosen the lower lock tab from
the mounting plate.
Move the range extender upwards to
unhook it from the mounting plate.
Pick up the range extender towards you to
remove it from the mounting plate.
STEP 1 STEP 2
STEP 3 STEP 4
To remove the range extender from the e-bike, follow these steps:
STEP 5
6.5. Removing the range extender battery
