EN-GB - 19HYENA E-BIKE SYSTEMS
7.2. Technical data of the charger
Item Specication
Charging current (max.) 2 A
Rated Input voltage 100 to 240 VAC
Input frequency range
47–63 Hz
Rated output voltage 42 ± 0.2V
Charging time, approx.
3 hours 30 minutes (from empty to full; per
single battery)
Permitted charging temperature range 0°C (32°F) to 40°C (104°F)
Storage temperature -20°C (-4°F) to 55°C (131°F)
AC Plug Charging plug
7.3. Charging the battery
► Before charging
• Inspect the charging socket and charger for damage regularly. Never charge the battery,
or use the e-bike, if you suspect it to be damaged or broken.
• Make sure the socket and AC plug of the charger are undamaged and dry before connecting
and charging the battery.
► Indicator on charger
• During the charging process, the LED indicator on the charger will illuminate red.
• When the battery is fully charged, the LED indicator on the charger will turn green.
Charging
Fully charged
Note
If the red LED indicator ashes during the charging process, a charging error has occurred.
In that case, immediately remove the charger from the socket. Discontinue the use of the
assist system and contact your local authorised bike shop.
