Page 19 of 36 Pages
Ball and T
ee Handle Installation
NOTE
Standard hand-tightening
with 1/4" short arm hex key
wrench will not
over
-torque screw
.
TORQUE TO
90-110 IN-LBS
(10-12.5 Nm)
TORQUE TO
90-110 IN-LBS
(10-12.5 Nm)
CAUTION
When installing tee handle
do not torque screw to
more than 14 ft. lbs.
CA
UTION
When Installing
ball handle do not
torque screw to
more than 10 ft. l
bs.
18
20
